Genset Model CP1200GFJ22

Electric Power (kW) 1200

Electric Efficiency (%) 40

Thermal Efficiency (%) 44

Overall Efficiency (%) 84

Dimensions (L×W×H, mm) 7409×1822×2325

Weight (kg) 19000

NOx Emissions (mg/Nm³) ≤500mg

Number of Cylinders 16V

Bore/Stroke (mm) 190/230

Displacement (L) 104.34

Speed (r/min) 1000

Genset Model CP900GFJ21

Electric Power (kW) 900

Electric Efficiency (%) 38

Thermal Efficiency (%) 45

Overall Efficiency (%) 83

Dimensions (L×W×H, mm) 6400×1950×2175

Weight (kg) 15000

NOx Emissions (mg/Nm³) ≤500mg

Number of Cylinders 12V

Bore/Stroke (mm) 190/230

Displacement (L) 78.25

Speed (r/min) 1000

Genset Model CP700GFJ11

Electric Power (kW) 700

Electric Efficiency (%) 38

Thermal Efficiency (%) 45

Overall Efficiency (%) 83

Dimensions (L×W×H, mm) 6300×1950×2175

Weight (kg) 14000

NOx Emissions (mg/Nm³) ≤500mg

Number of Cylinders 12V

Bore/Stroke (mm) 190/210

Displacement (L) 71.45

Speed (r/min) 1000

Fuel Adaptability Compatible with high hydrogen/CO content

Inherent Safety Shunt intake and turbocharging

Technological Advancement In-cylinder mixing amp; single-cylinder control

Electric Efficiency Load Rate 40%，≥90%

Model X Vertical modular structure

SE4 Intelligent control system

Cost-Effectiveness Highly competitive

Self Development Full self-sufficiency in core components

Reliability High-explosion-pressure design
