The Processing Capacity of Pure Methane 14Nm³/min

Minimum Intake Concentration (CH₄, Vol%) 0.5%

Normal Operating Concentration (CH₄, Vol%) 1%-1.2%

Startup Fuel Diesel

Startup Time ≤5h

Heat Supply at Rated Conditions ≥4.2 million kcal

CO Emissions ≤10mg/Nm³

NOx Emissions None

Intelligent Control System Self-developed, exceptional adaptability, safe, efficient, and intelligent

Human-Machine Interface (HMI) High integration, user-friendly, unmanned operation

Primary Mixing System Ensures safe gas delivery

Secondary Flame Arresting Explosion Relief System Automated control for system safety

Secondary Mixing System High thermal utilization with inherent safety design

Electromagnetic Quick-Acting Shutoff Valve Rapid response, zero leakage

Methane Concentration Analyzer Fast response, cross-calibration capability

Polycrystalline Ceramics High thermal shock resistance, extreme temperature tolerance, and large specific heat capacity

Comprehensive Safety System Design

Advanced Control System

Modular Design

Energy Efficiency Environmental Protection

Patented Technology for Low-Oxygen Hot Air Control

Short Startup Time

Independent Intellectual Property Rights
